RAV4 Design

5 Door SUV

RAV4 - Design - 5 Door SUV
from £39,885.00
  • 18" Dark Silver Alloy wheels (5-double-spoke)
  • 10.5" Toyota Smart Connect multimedia system with wireless Apple CarPlay™ and wired Android Auto™
  • Toyota Smart Connect with Navigation
129 - 132 g/km
48.7 - 49.5 mpg
2.5 Petrol Hybrid

POST https://dxp-webcarconfig.toyota-europe.com/v1/compare-v2/gb/en

  • Exterior Length (mm)
    4600 mm
  • Exterior Width (mm)
    1855 mm
  • Exterior Height (mm)
    1685 mm
  • Front Tread (mm)
    1610 mm
  • Rear Tread (mm)
    1640 mm
  • Overhang Front (mm)
    910 mm
  • Overhang Rear (mm)
    1000 mm
  • Wheelbase (mm)
    2690 mm
  • Luggage Capacity (Laden To Roof)
    733 litres
  • Luggage Capacity (Rear Seats Down, Laden To Roof)
    1690 litres
  • Minimum Running Ground Clearance (mm)
    190 mm
  • Departure Angle (°)
    20 °
  • Ramp Break-Over Angle (°)
    15.5 °
  • Limit Angle of Vehicle Turnover (°)
    52 °
  • Climbing Angle (°)
    18 °
  • Wading Depth (mm)
    500 mm
  • Limit Angle of Vehicle Turn Over
    52 °

  • CO2 Combined WLTP (g/km)
    129 g/km
  • Fuel Economy - Combined Min WLTP (mpg)
    48.7 mpg
  • Fuel Economy - Combined Max WLTP (mpg)
    49.5 mpg
  • CO2 Combined WLTP - Max (g/km)
    132 g/km
  • Hydrocarbons, THC (mg/km)
    16.9 mg/km
  • Hydrocarbons, NMHC (mg/km)
    13.5 mg/km
  • Nitrogen Oxides, NOx (mg/km)
    2.2 mg/km
  • Sound Level Drive By (dB(A))
    68.0 dB(A)
  • Euro Class
    Euro 6 AP
  • Fuel Grade - Recommended
    95 or more (octane)
  • Fuel Tank Capacity
    55 l
  • Carbon Monoxide, CO (mg/km)
    173.1 mg/km
  • Total Hybrid System Output (DIN hp)
    218 DIN hp
  • Total Hybrid System Output (kW)
    160 kW
  • Engine Code
    A25a-fxs
  • Displacement (cc)
    2487 cc
  • Bore x Stroke (mm x mm)
    87.50 x 103.48 mm
  • Compression Ratio
    14.0:1
  • Number Of Cylinders
    4 Cylinder, In Line
  • Valve Mechanism
    16-Valve DOHC, VVT-iE (intake), VVT-i (Exhaust)
  • Fuel Injection System
    Fuel injection
  • Maximum Output (DIN hp)
    218 DIN hp
  • Maximum Output (kW@rpm)
    160 kW@rpm
  • Maximum Torque (Nm@rpm)
    221/3600-5200 Nm@rpm
  • Hybrid Vehicle Battery: Type
    Lithium-ion
  • Hybrid Vehicle Battery: Capacity Ah (hr)
    4.3 Ah
  • Hybrid Vehicle Battery: Number Of Modules
    34
  • Electric Front Motor: Type
    permanent magnet synchronous motor
  • Electric Front Motor: Maximum Output (kW)
    88 kW
  • Electric Front Motor: Maximum Torque (Nm)
    202 Nm
  • Transmission Type
    Automatic
  • Drive
    Fwd
  • Maximum Speed (mph)
    111 mph
  • Acceleration 0-62 (mph)
    8.4 seconds
  • Drag Coefficient
    0.32
  • Suspension Front
    Macpherson strut
  • Suspension Rear
    Double wishbone
  • Brakes Front
    Ventilated Disc 2-Cylinder
  • Brakes Rear
    Ventilated Disc 1-Cylinder
  • Wheel Size
    225/60r18 100h 18x7j et35
  • Gross Train Weight - Total (kg)
    2930 kg
  • Gross Vehicle Weight (kg)
    2130 kg
  • Maximum Trailer Weight - Braked (kg)
    800 kg
  • Maximum Trailer Weight - Unbraked (kg)
    750 kg
  • Number of Seats
    5 seats
  • Interior length (mm)
    1890 mm
  • Interior Width (mm)
    1515 mm
  • Interior Height (mm)
    1230 mm
  • Turning Radius Tyre (m)
    5.5 m
  • Turning Radius Body (m)
    5.9 m

Interior
  • 6 speakers
  • Toyota Smart Connect with Navigation
  • Bluetooth® Connectivity
  • Digital Audio Broadcast (DAB)+
  • Connected Services
  • Voice recognition
  • Smart Voice Assist
  • 10.5" Toyota Smart Connect multimedia system with wireless Apple CarPlay™ and wired Android Auto™
  • USB connector
  • 10.5" multimedia display
  • Wireless Smartphone integration incl Apple CarPlay™
Exterior
  • Gloss Black roof rails
Interior
  • 1.5 litre bottle holder
  • Coat hooks - 2 rear
  • Dual-level deckboard
  • Dual-sided boot floor (carpet & plastic)
  • Front bottle holders
  • Front cup holders
  • Lockable glovebox
  • Passenger-only seatback pocket
  • Rear bottle holders
  • Rear console box
  • Rear cup holders
  • Retractable tonneau cover
  • Single compartment glovebox
  • Sunglasses holder
Exterior
  • Temporary spare wheel
  • 18" Dark Silver Alloy wheels (5-double-spoke)
Exterior
  • Auto headlights
  • Auto wipers
  • Auto-retractable door mirrors
  • Boot door release with Push-button
  • Power-adjustable door mirrors
  • Electric heated door mirrors
  • Follow-me-home headlights
  • Power tailgate
  • Remote boot door release in cabin
  • Remote boot door release on key
  • Smart Entry & Push-button start (with Motion Sensor Key)
  • Hazard lights - Remote
  • Smartphone remote door locking operation
  • Smartphone remote door lock notifications
  • Smartphone hazard lights operation
Interior
  • 12v power outlet - Boot
  • 12v power outlet - Front x 2
  • 60:40 split-folding rear seats
  • Adaptive Cruise Control (ACC) switch on steering wheel
  • Adjustable Speed Limiter (ASL) switch on steering wheel
  • Anti-jam protection on power windows
  • Assist grips - Front
  • Assist grips - Rear
  • Audio switches on steering wheel
  • Auto-dimming rear view mirror
  • Automatic High Beam (AHB) on/off switch
  • Central armrest
  • Child safety door lock
  • Clean air filter
  • Driver & front passenger personal LED lights
  • Dual-zone automatic air conditioning
  • Dynamic guide lines on Reversing Camera
  • ECO-driving Indicator
  • Front power windows
  • Electric Power Steering (EPS)
  • Auto up & down function on power windows
  • Hybrid System Indicator
  • Illuminated entry system
  • Intermittent windscreen wipers
  • Key reminder warning
  • Lane Departure Alert (LDA) switch on steering wheel
  • LED Boot light
  • LED Centre room light
  • Light on driver sun visor
  • Light on passenger sun visor
  • Manual telescopic steering wheel
  • Manual tilt steering wheel
  • Manually height-adjustable driver seat
  • Mirror on driver sun visor
  • Mirror on passenger sun visor
  • Multi-info switches on steering wheel
  • Pollen air filter
  • Power door lock
  • Push-button start
  • Rear door armrests
  • Rear passenger air vents
  • Rear power windows
  • Rear window defogger
  • Reclining rear seats
  • Speed-detecting automatic door lock
  • Telephone switches on steering wheel
  • Toyota Easy Flat system
  • Voice recognition switch on steering wheel
  • Smartphone remote air conditioning system
  • 12.3" digital combimeter
Interior
  • HUB FIT - Floor Mats
  • HUB FIT - Wheel Nuts
  • GR-SPORT Scuff Plates
Exterior
  • Adjustable Speed Limiter (ASL)
  • Anti-lock Braking System (ABS) with Electronic Brake force Distribution (EBD)
  • Automatic headlight levelling
  • Automatic High Beam (AHB)
  • Brake Assist (BA)
  • Driver Attention Alert
  • eCall emergency call system
  • Emergency Brake-light Signal (EBS)
  • Front parking sensors
  • Full-range Adaptive Cruise Control
  • Glass-breaking alarm sensors
  • Hill-start Assist Control (HAC)
  • Immobiliser
  • Indicators integrated on door mirrors
  • Intelligent Adaptive Cruise Control
  • Intrusion Alarm
  • Lane Departure Alert (LDA) with Steering Control
  • Lane Trace Assist (LTA)
  • LED Daytime running lights
  • LED Front fog lights
  • LED High mounted stop light
  • LED Multi-reflector headlights
  • LED Rear brake lights
  • LED Rear combination lights
  • Motion sensor alarm
  • Pre-Collision System with Pedestrian and Cyclist Detection
  • Rear parking sensors & reverse camera
  • Reversing Camera
  • Road Sign Assist (RSA)
  • Alarm with tilt detection sensors
  • Trailer Sway Control (TSC)
  • Tyre Pressure Warning System (TPWS)
  • Vehicle Stability Control (VSC)
  • Road Events
Interior
  • Adjustable Driver seat belt extender
  • Adjustable Front Passenger seat belt extender
  • Driver & front passenger Whiplash Injury Lessening (WIL) seats
  • Front passenger airbag detector
  • Front seat belt reminder
  • ISOFIX child restraint system
  • Passenger airbag on/off-switch
  • Seat belt pre-tensioners and force limiters
  • Rear headrests (3)
  • Rear seat belt reminder
  • Supplemental Restraint System (SRS) airbags - 7 airbags
  • Rear seat reminder
Exterior
  • Drive mode selector
  • Dual exhaust pipes
  • Rear spoiler
Interior
  • Electronic parking brake
Exterior
  • Black protection moulding on side doors
Interior
  • Floor mats
Exterior
  • Black front bumper
  • Black rear bumper
  • Black surrounds on front fog lights
  • Black wheel arch moulding
  • Body-coloured door handles
  • Body-coloured door mirrors
  • Body-coloured rear spoiler
  • Body-coloured shark-fin antenna
  • Dark grey painted upper front grille
  • LED Front light guide
  • LED Rear light guide
  • Meshed upper front grille
  • Privacy Glass
  • Shark-fin antenna
  • Silver front under-run
  • Silver insert on boot door
  • Silver rear under-run
Interior
  • Black insert on centre console
  • 3-spoke Leather steering wheel
  • Gloss Black centre console
  • Black upper dashboard
  • Chrome gear shift surround
  • Chrome insert on centre air vents
  • Chrome insert on side air vents
  • Chrome insert on steering wheel
  • Grey roof lining
  • Leather gear shift
  • Synthetic leather door trim
  • Synthetic leather front door armrests
  • Open tray on passenger dashboard
  • Rear armrest
  • Satin chrome interior door handles
  • Silver gear shift surround on centre console
  • Silver insert on front door assist grips
  • Silver insert on upper dashboard
  • Soft-touch texture on lower dashboard
  • Soft-touch texture on upper dashboard
  • White ambient lighting in footwell
  • Illuminated power window switches
Exterior
  • HUB FIT - Badge
  • Scuff Plates
  • Hybrid Key Cover
  • Door Handle Film
  • Rear Bumper Film
  • Safety Kit
