Corolla Hatchback Design

5 Door Hatchback

Corolla Hatchback - Design - 5 Door Hatchback
from £32,140.00
  • 17" Black Machined-face Alloys wheels (5-double-spoke)
  • Smart Entry & Push-button Start
  • Auto wipers
104 - 111 g/km
57.6 - 61.4 mpg
1.8 Petrol Hybrid (140 hp)
Corolla Hatchback - Design - 5 Door Hatchback
Juniper Blue (Metallic Paint)

POST https://dxp-webcarconfig.toyota-europe.com/v1/compare-v2/gb/en

  • Exterior Length (mm)
    4370 mm
  • Exterior Width (mm)
    1790 mm
  • Exterior Height (mm)
    1460 mm
  • Front Tread (mm)
    1530 mm
  • Rear Tread (mm)
    1530 mm
  • Overhang Front (mm)
    935 mm
  • Overhang Rear (mm)
    795 mm
  • Wheelbase (mm)
    2640 mm
  • 2 Seat Mode (Laden To Roof)
    1004 litres
  • Deck Length (mm)
    743 mm
  • Deck Width (mm)
    1416 mm
  • Deck Height (mm)
    753 mm
  • Load Volume (m³)
    0.352 m³
  • VDA luggage capacity, rear seat up (liters)
    313 litres
  • Minimum Running Ground Clearance (mm)
    135 mm

  • CO2 Combined WLTP (g/km)
    104 g/km
  • Fuel Economy - Combined Min WLTP (mpg)
    57.6 mpg
  • Fuel Economy - Combined Max WLTP (mpg)
    61.4 mpg
  • CO2 Combined WLTP - Max (g/km)
    111 g/km
  • Sound Level Drive By (dB(A))
    68 dB(A)
  • Euro Class
    Euro 6 AP
  • Fuel Grade - Recommended
    91 or more (octane)
  • Fuel Tank Capacity
    43 l
  • Total Hybrid System Output (DIN hp)
    140 DIN hp
  • Total Hybrid System Output (kW)
    103 kW
  • Engine Code
    2zr-fxe
  • Displacement (cc)
    1798 cc
  • Bore x Stroke (mm x mm)
    80.5 x 88.3 mm
  • Compression Ratio
    13.048:1
  • Number Of Cylinders
    4 Cylinder, In Line
  • Valve Mechanism
    16-valve DOHC, chain drive with dual VVT-i
  • Fuel Injection System
    Fuel injection
  • Maximum Output (DIN hp)
    140 DIN hp
  • Maximum Output (kW@rpm)
    103 kW@rpm
  • Maximum Torque (Nm@rpm)
    142/3600-3600 Nm@rpm
  • Hybrid Vehicle Battery: Type
    Lithium-ion
  • Hybrid Vehicle Battery: Capacity Ah (hr)
    4.08 Ah
  • Battery Capacity (Ah)
    4.08 Ah
  • Electric Front Motor: Type
    Permanent magnet synchronous motor
  • Electric Front Motor: Maximum Output (kW)
    70 kW
  • Electric Front Motor: Maximum Torque (Nm)
    185 Nm
  • Transmission Type
    Automatic
  • Drive
    Fwd
  • Maximum Speed (mph)
    111 mph
  • Acceleration 0-62 (mph)
    9.1 seconds
  • Suspension Front
    Macpherson strut
  • Suspension Rear
    Double wishbone
  • Brakes Front
    Ventilated disc 1-cylinder
  • Brakes Rear
    Solid disc 1-cylinder
  • Gross Train Weight - Total (kg)
    2660 kg
  • Gross Vehicle Weight (kg)
    1910 kg
  • Kerb Weight / Unladen Weight (kg)
    1385-1485 kg
  • Maximum Trailer Weight - Braked (kg)
    750 kg
  • Maximum Trailer Weight - Unbraked (kg)
    450 kg
  • Gross Vehicle Weight - Front (kg)
    1050 kg
  • Gross Vehicle Weight - Rear (kg)
    970 kg
  • Number of Seats
    5 seats
  • Interior length (mm)
    1795 mm
  • Interior Width (mm)
    1510 mm
  • Interior Height (mm)
    1155 mm
  • Turning Radius Tyre (m)
    5.4 m
  • Turning Radius Body (m)
    5.7 m

Interior
  • 6 speakers
  • Toyota Smart Connect + with Navigation
  • Bluetooth® Connectivity
  • Digital Audio Broadcast (DAB)
  • MyT Connected Services
  • USB connector
  • Voice recognition
  • Smartphone integration incl Apple CarPlay™ & Android Auto™
  • Smart Voice Assist
  • 10.5" Toyota Smart Connect + multimedia system with navigation & wireless Smartphone integration incl Apple CarPlay™
  • 10.5" multimedia display
  • Front USB device charger
Interior
  • Coat hooks - 2 rear
  • Front bottle holders
  • Front console box
  • Front cup holders
  • Front door pockets
  • Glovebox with light
  • Parcel shelf
  • Passenger-only seatback pocket
  • Rear bottle holders
  • Rear cup holders
  • Rear door pockets
  • Shopping bag hooks
  • Single compartment glovebox
Exterior
  • 17" Black Machined-face Alloys wheels (5-double-spoke)
  • Tyre Repair Kit (TRK)
Exterior
  • Auto headlights
  • Auto wipers
  • Auto-retractable heated door mirrors
  • Power-adjustable door mirrors
  • Electric heated door mirrors
  • Remote door lock
  • Smart Entry & Push-button Start
Interior
  • 12v power outlet - Front
  • Adaptive Cruise Control (ACC) switch on steering wheel
  • Adjustable Speed Limiter (ASL) switch on steering wheel
  • Aerofins on rear window
  • Anti-jam protection on power windows
  • Assist grips - Rear
  • Audio switches on steering wheel
  • Auto-dimming interior rear view mirror
  • Black armrest on centre console box
  • Boot light
  • Child safety door lock
  • Clean air filter
  • Driver & front passenger personal LED lights
  • Dual-zone automatic air conditioning
  • Auto up & down function on power windows
  • Forward tilting 2nd row rear seats
  • Heated driver & front passenger sport seats
  • Key reminder warning
  • Lane Departure Alert (LDA) switch on steering wheel
  • LED Centre room light
  • Light on driver sun visor
  • Light on passenger sun visor
  • Manual telescopic steering wheel
  • Manual tilt steering wheel
  • Manually height-adjustable driver seat
  • Manually height-adjustable front passenger seat
  • Manually sliding driver seat
  • Manually sliding front passenger seat
  • Mirror on driver sun visor
  • Mirror on passenger sun visor
  • Multi-info switches on steering wheel
  • Noise reduction layer on windscreen
  • Pollen air filter
  • Power door lock
  • Power passenger window lock
  • Power-adjustable lumbar support on driver seat
  • Push-button start
  • Rear window defogger
  • Rear window wiper
  • Sliding central armrest
  • Static guide lines on Reversing Camera
  • Telephone switches on steering wheel
  • UV-filter on driver & front passenger windows
  • Voice recognition switch on steering wheel
  • Wireless mobile phone charger
  • Colour multi-information display with 3D effect
  • Remote air conditioning system
  • Nanoe-X® air purifier
  • 12.3" Combimeter screen
Exterior
  • Adaptive Automatic High Beam (AHB)
  • Adjustable Speed Limiter (ASL)
  • Driver Attention Alert
  • eCall emergency call system
  • Emergency Brake-light Signal (EBS)
  • Front parking sensors
  • Lane Departure Alert (LDA) with Steering Control
  • Lane Trace Assist (LTA)
  • LED Daytime running lights
  • LED Dual-beam Projector headlights
  • LED Front fog lights
  • Manual headlight levelling
  • Rear parking sensors
  • Reversing Camera
  • Road Sign Assist (RSA)
  • Tyre Pressure Warning System (TPWS)
  • Vehicle Stability Control (VSC)
  • Front & Rear Parking Sensors with Auto Brake
  • Emergency Steering Assist
  • Intelligent Adaptive Cruise Control (iACC)
  • Acoustic Vehicle Alert System
  • Pre-Collision System with Pedestrian (day & night), Cyclist & Motorbike (day) Detection
  • Front-to-front Oncoming Car & Motorbike daytime detection
  • Acceleration Suppression at low speed
  • Toyota Safety Sense with Over-the-Air Updates
  • Pre-Collision System - with Intersection detection
  • Proactive Driving Assist (PDA)
Interior
  • Adjustable rear headrests
  • Front seat belt reminder
  • ISOFIX child restraint system
  • Passenger airbag on/off-switch
  • Pre-tensioners and force limiters
  • Rear headrests (3)
  • Rear seat belt reminder
  • Supplemental Restraint System (SRS) airbags - 7 airbags
  • Rear seat reminder
Exterior
  • Body-coloured front spoiler
Interior
  • Electronic parking brake
Interior
  • Floor mats
Exterior
  • B - Pillar in Black
  • Black metallic lower front grille
  • Body-coloured door handles
  • Body-coloured door mirrors
  • Body-coloured rear bumper
  • Body-coloured rear spoiler
  • Body-coloured shark-fin antenna
  • Meshed lower front grille
  • Gloss black upper front grille
  • Rear bumper with chrome plated inserts
  • Satin chrome surround on lower front grille
  • Privacy Glass
Interior
  • 3-spoke Leather steering wheel
  • Aluminium door scuff plates
  • Leather gear shift
  • Synthetic Leather armrest
  • Power windows switches with satin chrome inserts
  • Rear armrest
  • Satin chrome gear shift surround on centre console
  • Satin chrome insert on centre air vents
  • Satin chrome insert on dashboard
  • Satin chrome interior door handles
  • Satin chrome surround on multimedia display
  • Satin chrome surround on speedometer
  • Soft-touch texture on upper dashboard
  • White ambient lighting on front cup holders & open tray
  • White ambient lighting on open tray
  • COROLLA door scuff plates

Read timed out

POST https://dxp-webcarconfig.toyota-europe.com/v1/equipment-optional/gb/en?modelId=881ef498-b467-4895-8074-cbc4340ccc81&carId=ff5eedd8-318d-49be-8da0-a3e2e12ac3d6&carColourId=34aef4c3-94a4-4c59-afc6-93954d735e32

Corolla-HB - Design - 5 Door Hatchback
  • 2640
  • 4370
  • 1530
  • 1790
  • 1530
  • 1790
  • 1460

  • Corolla-HB - Design - 5 Door Hatchback
  • Corolla-HB - Design - 5 Door Hatchback
  • Corolla-HB - Design - 5 Door Hatchback

Standard equipment

Build

From intelligent safety systems to intuitive interior features, every Toyota leaves the factory with a wealth of essential equipment as standard. Find out more about the standard equipment available on your Toyota vehicle below:

17" Black Machined-face Alloys wheels (5-double-spoke) 0
17" Black Machined-face Alloys wheels (5-double-spoke)
Tyre Repair Kit (TRK) 0
Tyre Repair Kit (TRK)

POST https://dxp-webcarconfig.toyota-europe.com/v1/equipment-standard/gb/en?modelId=881ef498-b467-4895-8074-cbc4340ccc81&carId=ff5eedd8-318d-49be-8da0-a3e2e12ac3d6&carColourId=34aef4c3-94a4-4c59-afc6-93954d735e32

Explore features by grade

New Corolla Hatchback

4 Options

  • Corolla Hatchback - Icon - 5 Door Hatchback

    Corolla Hatchback Icon

    Hybrid
    5 Door Hatchback
    • +
      16" Alloy wheels (5-double-spoke)
    • +
      Toyota Safety Sense with Over-the-Air Updates
    • +
      12.3" Combimeter screen

    Select Engine


    from £30,505.00

    Automatic | Front Wheel Drive - FWD
    • WLTP CO2
      100 - 111 g/km
    • Fuel Economy
      57.6 - 64.1 mpg

    from £32,250.00

    Automatic | Front Wheel Drive - FWD
    • WLTP CO2
      101 - 111 g/km
    • Fuel Economy
      57.6 - 62.7 mpg
  • Corolla Hatchback - Design - 5 Door Hatchback

    Corolla Hatchback Design

    Hybrid
    5 Door Hatchback
    • +
      17" Black Machined-face Alloys wheels (5-double-spoke)
    • +
      Smart Entry & Push-button Start
    • +
      Auto wipers

    Select Engine


    from £32,140.00

    Automatic | Front Wheel Drive - FWD
    • WLTP CO2
      104 - 111 g/km
    • Fuel Economy
      57.6 - 61.4 mpg

    from £33,885.00

    Automatic | Front Wheel Drive - FWD
    • WLTP CO2
      105 - 111 g/km
    • Fuel Economy
      57.6 - 60.1 mpg
  • Corolla Hatchback - GR SPORT - 5 Door Hatchback

    Corolla Hatchback GR SPORT

    Hybrid
    5 Door Hatchback
    • +
      18" Gloss Black Machined-face Alloy wheels (10-spoke)
    • +
      10.5" Toyota Smart Connect + multimedia system with navigation & wireless Smartphone integration incl Apple CarPlay™
    • +
      Front & Rear Parking Sensors with Auto Brake

    Select Engine


    from £33,405.00

    Automatic | Front Wheel Drive - FWD
    • WLTP CO2
      105 - 111 g/km
    • Fuel Economy
      57.6 - 60.1 mpg

    from £35,150.00

    Automatic | Front Wheel Drive - FWD
    • WLTP CO2
      106 - 111 g/km
    • Fuel Economy
      57.6 - 60.1 mpg
  • Corolla Hatchback - Excel - 5 Door Hatchback

    Corolla Hatchback Excel

    Hybrid
    5 Door Hatchback
    • +
      18" Bi-tone Dark Grey & Machined-face Alloy wheels (5-double-spoke)
    • +
      Head Up Display (HUD)
    • +
      Blind Spot Monitor with Safe Exit Assist

    Select Engine


    from £34,240.00

    Automatic | Front Wheel Drive - FWD
    • WLTP CO2
      106 - 111 g/km
    • Fuel Economy
      57.6 - 60.1 mpg

    from £35,985.00

    Automatic | Front Wheel Drive - FWD
    • WLTP CO2
      106 - 111 g/km
    • Fuel Economy
      57.6 - 60.1 mpg
